Large capacity 110 kw submersible water pump

Large capacity 110 kw submersible water pump

Model NO.: SS
Price:: USD 1263.00-2996.00 / set
Delivery: FOB
Minimum order quantity: 1 set
Supply Ability: 600 set / Quarterly
Country of Origin: Tianjin/ Qingdao/ Shanghai/Guangzhou/As customer required
Stock Time: Shipped in 15 days after payment Day

Quantity:

Product Description
Basic Information

Product Description

Electric submersible sludge sand dredging pump is capable of handling sand, gravel, solids and all kinds of sludge in diverse applications related to the dredging, construction, oil and mining industry as well as marine, energy, and industrial sectors. The heavy duty pumps are equipped with agitator that breaks down and re-suspends settled or compacted solids, allowing them to easily transfer a very high percentage of solids to water. We offer submersible dredges with capacities ranging from 100-10,560 US GPM. Our dredges are easy to assemble, transport and handle.

SPECIFICATIONS FOR SUBMERSIBLE SLURRY PUMP
Engine	Hydraulic	Kw	315
	Motor	Kw	315
	Frequency	Hz	50/60
Main performance parameters	Capacity	m3/h	20-2500
	Head	m	10-90
	Speed	rpm	980/1450
Other performance	Max Dredging Depth	m	30
	Weight Material Density	%	60
	Solids Size	mm	60

Main Features

1) Pump provided of agitator to stir things up.

2) High abrasion resistance.

3) Low rotation speed.

4) Able to handle up to 60% per weight material density.

Applications

1) Coal washing water

2) Sump cleaning and cleaning of settling ponds

3) Dredging

4) Coal and ore slurries

5) Grit removal in sewage treatments plants

6) Cooling water/mill scale pumping in iron/steel production

7) Bentonite pumping

8) Various drainage applications in quarries and mines

9) Nuisance slurry removal

10) Secondary processes in other industries that require pumps with very high durability

Detailed Images

Agitator Impeller

Material:chrome alloy

Brand: MST

Original:China

It stirs sand up, and cuts big gravel into small solids.

Auxiliary Agitator

Material:Mn-steel
Brand:MST
Power:5.5kw, 7.5kw, 11kw
The auxiliary agitator extends working scope, more pumping water.

Machine Parts

Material: chrome alloy
Brand:MST
Original: China

Main Features

Material: chrome alloy
Brand:MST
Parts:back plate, throat bush

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery

Packaging
Size	1700 (L) * 700 (W) * 1300 (H)
Weight	1.2 T
Packaging Details	The normal package is wooden box(Size: LWH). If export to european countries,the wooden box will be fumigated.If container is too tigher, we will use PE film for packing or pack it according to customers special request.

Packaging
Size	1600 (L) * 600 (W) * 850 (H)
Weight	1.1 T
Packaging Details	The normal package is wooden box(Size: LWH). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
